Product Details


Product Name2000 Series Aluminum checkered plate
Thickness1.0mm-6.0mm
Application FieldMainly used in aircraft structure (such as skin, etc.), aerospace, weapons, engines,Piston, automobile body, ship hull and stress components, etc.
SpecificationAlloy2017、2024、2A12
State O、T3、T351、T361、T4、T6、T81
Film typeBlue film, electrostatic blue film transparent film, black and white film, laser film, paper clip, stamping film, stretch film
Product Details2017The 2017 aluminum plate is a typical duralumin in al-Cu-Mg system, with good comprehensive performance and the largest amount of duralumin.
2024Also known as duralumin, the main alloying element is copper. Has high strength and good cutting performance, has a certain heat resistance, heat treatment, the disadvantage is poor corrosion resistance
2A122A12 aluminum plate products belong to high strength duralumin, which can be strengthened by heat treatment and has good weldability by spot welding.
Product Usage2017Aluminum plate is usually used in rivets, general machinery parts, aircraft, ships, transportation, building structural parts, transport vehicle structural parts, propeller components and accessories, etc.
2024Mainly used in aircraft structure (such as skin, etc.), aerospace, weapons, engines, pistons, automobile body, ship hull and stress components, etc.
2A122A12 aluminum plate is mainly used for machine exterior parts structure (skin, skeleton, rib beam, frame, etc.), wings, molds, military, transportation vehicles, compressors, rivets, missile components, truck wheels, spiral pulp components and other various structural parts.



Product Namealuminum sheet
Capacity1000 tons/month
CertificationsISO 9001
Material1000, 2000, 3000, 4000, 5000, 6000seriesa) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc.b) 2000 Series: 2014, 2024, etc.c) 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc.d) 4000 Series: 4045, 4047, 4343, etc.e) 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5454, 5754, 5A06, etc.f) 6000 Series: 6061, 6063, 6082, 6A02, etc.
Thickness0.3-14mm
Width50-2000 mm
Coil Weight2-6 tons
Payment30% despoit in advance,70% balance before delivery
Application1)Further making utensil.
2)Solar reflective film
3)The appearance of the building
4)Interior decorating:ceilings,walls,etc.
5)Furniture cabinets
6)Elevator decoraction
7)Signs,nameplate,bags making.
8)Decorated inside and outside the car
9)Household appliances:refrigerators,microwave ovens,audio equipment,etc.
10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Container size20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)聽24-26CBM
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
TemperO/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc.
SpecificationThickness≤30mm; Width≤2200mm Length≤12000mm OR Coil (C)
ApplicationDecoration, heat-sink device, external walls, storage, sheets for construction, etc.
FeatureGood rust resistance, not suitable for heat treatments, good corrosion resistant
performance, well welding property, good plasticity, low strength but suitable
for cold working hardening
